Commercial Vehicle Low Pressure Alarm 203 Psi OTR TPMS
12V1 433.92MHZ OTR sensors ten tires Truck TPMS For Engineering vehicle non include repeater
Features
* you must use more repeaters when you use trailer
* Convertible pressure unit, Bar/Psi
Product parameters
Commercial vehicle repeater
Machine port:Vehicle battery ACC input(24V)
Machine weight (excluding packaging):120g±3g
working temperature:-40-85℃
Normal current:4.5mA
Reception sensitivity:-95dbm
| OTR sensors |
|
| Dimensions |
Φ2.4cm(diameter)*2cm( height ) |
| Plastic parts material |
Nylon + glass fiber |
| Metal part material |
copper |
| Shell temperature resistance |
-50℃-150℃ |
| Thread Size |
12V1 internal thread(customizable) |
| Machine weight (excluding packaging) |
23±1g |
| Power supply mode |
Button Battery |
| Battery model |
CR1632 |
| Battery capacity |
135mAh |
| Working voltage |
2.1V-3.6V |
| Transmit current |
8.7mA |
| Self-test current |
2.2mA |
| Sleep current |
0.5uA |
| Sensor working temperature |
-30℃-80℃ |
| Transmit frequency |
433.92MHZ |
| Transmit power |
-10dbm |
Main Features:
1. Support trucks , trailers . 2,6,8,10,12,14,16,18,20,22,24,26 wheels support .
2. LCD display with backlight
3. High temperature , low temperature ,high pressure, low pressure alarm .
4. Max pressure is 14bar , 203psi .
5. Support '' PSI'' '' BAR'' .
6. RF wireless technology,can auto-alarm,when tire pressure and temperature is abnormal.
7. Sensor waterproof grade: IP67.
FAQ
Q: Why Choose EGQ TPMS?
A: Professional tool worth having, UNIVERSAL FIT CAR TRUCK Protect your vehicle, Extend useful life of tyre.Save your FUEL cost, Enhance your driving ability ,The key reason should be repeated three times.
Keep you and your family safer,Keep you and your family safer,Keep you and your family safer.
Q. About the sample, what’s the cost of transportation? How long can I expect to get the sample ?
A: The freight depends on weight, packing size and your country or province region,etc.
The samples will be sent via international express such as DHL, UPS,TNT,FEDEX and would be arrived within 3~5 days.
Q. Can we have our logo or company name to be printed on your products or package?
A: Sure. If the quantity reach MOQ, your logo could be printed on your products by Hot stamping,
printing, Embossing, UV coating,Silk-screen printing or sticker.
Q. Do you have stock?
A: Most of products are under regular production,
we can make delivery immediately if we the specific one in stock.
